Digital TV Receiver, Electronics
ABS-CBN TVPlus Digital TV Receiver
Availability:
In stock
- Digital Tv Receiver
- 1080p resolution
- Video Decoding
₱780
In stock
| Weight | 1 kg |
|---|---|
| Dimensions | L 18 x W 11 x H 4.5 (cm) |
| KEY FEATURES | |
| FUNCTION | |
| Chipset | M3823 |
| Clock Speed | 675MHz, 1280DMIPS |
| FLASH | 8M SPI Flash |
| RAM | DDR3 – 128 MB |
| Video Decoding | MPEG-2 MP@HL,MP@ML MPEG-4.2 ASP@L5 (720P) H.264 (MPEG-4.10)BP@L3, [email protected], [email protected], resolution up to 1080p@30fps VC-1 Decoder, supports MP@HL and AP@L3 with resolution up to 1080p@30fps |
| Conditional Access | Verimatrix CAS |
| Cope Protection | Support |
| Audio Decoding | MPEG-1; MPEG-2 (Layers I, II); AAC, HE-AAC Level 2 & 4 audio decoding |
| Input Frequency Range | VHF 170-230MHz and UHF 470-862MHz supported |
| Channel Bandwidth | 6MHz |
| Channel Assignment | JAPAN TV broadcasting standard |
| ISDB-T Typical Input Level | (-75dBm to -15dBm) |
| Input Impedance | 75 ohm nominal |
| Channel Decoding | SDB-T |
| HARDWARE | |
| FRONT PANEL | |
| LED Status Indicator | Power – Red Standby – Yellow Signal – Green Infrared Remote Control Sensor |
| Power Button | Standby |
| Channel Switch | CH+/ CH |
| BACK PANEL | |
| ANT IN | Type F (female) |
| Video Output | 1 x Component Video and Audio (AV) out |
| USB Output | 1 x USB Host 2.0 |
| Power Outlet | Power Outlet |
| EXTERNAL POWER SUPPLY | |
| Input | AC 100-240 V, 50- 60 Hz |
| Output | DC 12V/1.0A |
| Warranty | 1 Year warranty on Parts and Labor |
